Roller chain pulse argon arc welding operation strategy: create high-quality roller chain
In the global industrial market roller chain is an indispensable transmission component in mechanical equipment. Its quality and performance directly affect the operating efficiency and reliability of many mechanical equipment. For international wholesale buyers, it is crucial to find a high-quality, precision-made roller chain supplier. As an advanced welding process, roller chain pulse argon arc welding technology plays a key role in the production and manufacturing of roller chains, and can significantly improve the quality and durability of roller chains. The following will introduce you to the specific operation of roller chain pulse argon arc welding in detail.
1. Overview of roller chain pulse argon arc welding
Pulse argon arc welding is an advanced welding technology that uses argon as a shielding gas to generate arc discharge during welding, and melts and connects the welding materials together in the form of pulse current. For the manufacture of roller chains, pulse argon arc welding can achieve a firm connection between the various components of the roller chain, ensuring the normal operation of the roller chain under complex working conditions.
2. Roller chain pulse argon arc welding equipment and material preparation
Welding equipment: Choosing a suitable pulse argon arc welding machine is the key. According to the specifications and production requirements of the roller chain, determine the power, pulse frequency and other parameters of the welding machine. At the same time, ensure that the welding machine has good stability and reliability so as to maintain a stable arc and welding quality during long-term welding work. In addition, auxiliary equipment such as argon gas cylinders, welding guns, and control panels are also required.
Welding materials: Selecting welding wire that matches the material of the roller chain is the basis for ensuring welding quality. Usually, the material of the roller chain is alloy steel or carbon steel, so the welding wire should also be selected from the corresponding alloy steel or carbon steel welding wire. The diameter of the welding wire is generally between 0.8mm and 1.2mm, and it is selected according to the actual welding needs. At the same time, ensure that the surface of the welding wire is smooth, free of oil and rust, so as to avoid defects such as pores and inclusions during welding.
3. Operation steps of roller chain pulse argon arc welding
Preparation before welding: Clean and derust the various components of the roller chain to ensure that the welding surface is clean, free of oil and impurities. For some roller chain components with complex structures, chemical cleaning or mechanical cleaning methods can be used for pretreatment. At the same time, check the equipment status of the welding machine to ensure that the argon gas flow is stable, the insulation performance of the welding gun is good, and the parameters of the control panel are set accurately.
Clamping and positioning: The parts to be welded of the roller chain are accurately clamped on the welding fixture to ensure the positioning accuracy and stability of the weldment. During the clamping process, avoid excessive clamping to cause deformation of the weldment, and pay attention to the centering and alignment of the weldment to ensure the dimensional accuracy and appearance quality after welding. For some longer roller chain parts, multi-point positioning can be used for fixing.
Arc ignition and welding: At the beginning of welding, first aim the welding gun at the welding starting point, and press the switch of the welding gun to ignite the arc. After arc ignition, pay attention to observe the stability of the arc, and adjust the welding current and pulse frequency appropriately to keep the arc burning stably. When starting welding, the angle of the welding gun should be appropriate, generally at an angle of 70° to 80° with the welding direction, and ensure that the distance between the welding wire and the weldment is moderate to ensure a good fusion effect.
Welding process control: During the welding process, pay close attention to the changes in welding parameters, such as welding current, voltage, pulse frequency, welding speed, etc. According to the material and thickness of the roller chain, these parameters should be reasonably adjusted to ensure the stability of the welding process and the welding quality. At the same time, pay attention to the swing amplitude and speed of the welding gun so that the welding wire is evenly filled into the weld to avoid defects such as too high, too low, and welding deviation. In addition, the flow and coverage of argon gas should be checked regularly to ensure that the weld area is fully protected to prevent oxidation and contamination of the weld.
Arc closure and post-weld treatment: When welding is nearing the end, the welding current should be gradually reduced to perform arc closure. When closure, the welding gun should be lifted slowly and stay at the end of the weld appropriately to fill the arc pit at the end of the weld to prevent defects such as arc pit cracks. After welding is completed, the weld should be visually inspected to check whether the surface quality, weld width, and weld leg size of the weld meet the requirements. For some surface defects, such as welding slag and spatter on the weld surface, they should be cleaned up in time. At the same time, according to the use requirements of the roller chain, the weld is subjected to non-destructive testing, such as ultrasonic testing, magnetic particle testing, etc., to ensure the quality of the inside of the weld. Finally, the roller chain after welding is heat treated to eliminate welding stress and improve the overall performance of the roller chain.
4. Selection of welding process parameters for roller chain pulse argon arc welding
Welding current and pulse frequency: welding current is one of the key parameters affecting welding quality and welding efficiency. For thicker roller chain parts, a larger welding current needs to be selected to ensure that the weld can be fully penetrated; for thinner parts, the welding current can be appropriately reduced to avoid welding through. At the same time, the selection of pulse frequency is also very important. A higher pulse frequency can make the arc more stable and the weld surface smoother and flatter, but the welding penetration is relatively shallow; while a lower pulse frequency can increase the welding penetration, but the stability of the arc is relatively poor. Therefore, in the actual welding process, the best combination of welding current and pulse frequency should be determined through experiments and experience according to the specific conditions of the roller chain.
Welding speed: welding speed determines the welding heat input and the forming effect of the weld. Too fast a welding speed will lead to insufficient weld penetration, narrow weld width, and even defects such as incomplete penetration and slag inclusion; while too slow a welding speed will cause the weld to overheat and the weld width to be too large, reducing welding efficiency and increasing the deformation of the weldment. Therefore, the welding speed should be reasonably selected according to factors such as the material, thickness, and welding current of the roller chain to ensure a balance between welding quality and welding efficiency.
Argon flow rate: The size of the argon flow rate directly affects the protection effect of the weld. If the argon flow rate is too small, an effective protective gas layer cannot be formed, and the weld is easily contaminated by the air, resulting in defects such as oxidation and nitrogen inclusion; if the argon flow rate is too large, it will cause problems such as pores in the weld and an uneven weld surface. In general, the selection range of argon flow rate is 8L/min to 15L/min, and the specific flow rate should be adjusted according to factors such as the model of the welding gun, the size of the weldment, and the welding environment.
5. Quality control and inspection of roller chain pulse argon arc welding
Quality control measures: In the process of roller chain pulse argon arc welding, a series of quality control measures need to be taken to ensure the welding quality. First of all, it is necessary to establish a complete welding process document and operating procedures, standardize the welding process parameters and operating steps, and ensure that the welding personnel strictly operate in accordance with the requirements. Secondly, it is necessary to strengthen the maintenance and management of welding equipment, regularly inspect and calibrate the welding machine, and ensure that the performance of the welding equipment is stable and reliable. In addition, strict quality inspection of welding materials is required to ensure that welding wire, argon gas, etc. meet the relevant standards and requirements. At the same time, during the welding process, it is necessary to strengthen the control of the welding environment to avoid the influence of environmental factors on the welding quality, such as wind, humidity, etc.
Detection method: For the roller chain after welding, a variety of detection methods are required for quality inspection. Appearance inspection is the simplest detection method, which mainly checks the appearance quality of the weld, such as whether there are cracks, welding slag, spatter and other defects on the weld surface, whether the weld width and weld leg size meet the requirements, and whether the transition between the weld and the parent material is smooth. Nondestructive testing methods mainly include ultrasonic testing, magnetic particle testing, penetration testing, etc. These methods can effectively detect defects inside the weld, such as cracks, incomplete penetration, slag inclusions, pores, etc. For some important roller chains, destructive testing, such as tensile testing, bending testing, hardness testing, etc., can also be performed to evaluate the overall performance and quality of the roller chain.
6. Common problems and solutions for roller chain pulse argon arc welding
Weld porosity: Weld porosity is one of the common defects in roller chain pulse argon arc welding. The main reasons include insufficient argon flow, oil and water stains on the surface of the welding wire or weldment, and too fast welding speed. In order to solve the problem of weld porosity, it is necessary to ensure that the argon flow is stable and sufficient, strictly clean and dry the welding wire and weldment, reasonably control the welding speed, and pay attention to the angle and distance of the welding gun to avoid air entering the welding area.
Weld crack: Weld crack is a more serious defect in roller chain welding, which may affect the normal use of the roller chain. The main reasons for weld cracks are excessive welding stress, poor weld fusion, and mismatch between welding materials and parent materials. To prevent weld cracks, it is necessary to reasonably select welding process parameters, reduce welding stress, ensure good weld fusion, and select welding materials that match the parent material. For some roller chain components that are prone to cracks, they can be preheated before welding and properly heat treated after welding to eliminate welding stress and reduce the risk of cracks.
Weld undercut: Weld undercut refers to the phenomenon of depression at the edge of the weld, which will reduce the effective cross-sectional area of the weld and affect the strength of the roller chain. Weld undercut is mainly caused by excessive welding current, excessive welding speed, improper welding gun angle, etc. To solve the problem of weld undercut, it is necessary to appropriately reduce the welding current and welding speed, adjust the angle of the welding gun, make the distance between the welding wire and the weldment moderate, ensure that the welding wire can be evenly filled into the weld, and avoid depression at the edge of the weld.
7. Safety precautions for roller chain pulse argon arc welding
Personal protection: When performing roller chain pulse argon arc welding, operators must wear personal protective equipment, including welding gloves, protective glasses, work clothes, etc. Welding gloves should be made of materials with good insulation and high temperature resistance to prevent high-temperature metal splashes generated during welding from scalding the hands; protective glasses should be able to effectively filter ultraviolet and infrared rays to protect the eyes from damage by welding arcs; work clothes should be flame-retardant materials and worn neatly to avoid skin exposure.
Equipment safety: Before using a pulse argon arc welder, carefully check the various safety performances of the equipment, such as whether the grounding of the welder is good, whether the insulation of the welding gun is intact, and whether the valve and pipeline of the argon cylinder are leaking. Welding operations can only be performed after ensuring that the equipment is in a safe and reliable state. During the welding process, pay attention to the operating status of the equipment. If abnormal sounds, odors, smoke, etc. are found, welding should be stopped immediately, the power supply should be cut off, and inspection and maintenance should be carried out.
On-site safety: The welding site should be well ventilated to avoid the accumulation of argon and harmful gases generated during welding, which may cause harm to the human body. At the same time, welding equipment, gas cylinders, etc. should be placed away from flammable and explosive items, and equipped with corresponding fire-fighting equipment, such as fire extinguishers and fire-fighting sand, to prevent fire accidents. In addition, obvious safety warning signs should be set up at the welding site to remind other personnel to pay attention to safety.
